[SVG] <radialGradient>

<radialGradient>

<radialGradient> 요소는 원형 그라디언트를 설정합니다.

<radialGradient>

<radialGradient> 요소는 원형 그라디언트를 설정합니다.

정의(Definition)

<radialGradient> 요소는 원형 그라디언트를 설정합니다.

1. 그라디언트

SVG를 이용한 그라디언트입니다.

Sample1

HTML

<div class="svgBox">
    <svg class="svg">
        <radialGradient id="radialGradient1" gradientUnits="userSpaceOnUse">
            <stop offset="0" style="stop-color: #f6d365" />
            <stop offset="1" style="stop-color: #fda085" />
        </radialGradient>
        <polygon fill="url(#radialGradient1)" points="130,128 65,148 15,102 30,36 95,16 145,62"></polygon>
    </svg>
    <svg class="svg">
        <radialGradient id="radialGradient2" gradientUnits="userSpaceOnUse">
            <stop offset="0" style="stop-color: #f6d365" />
            <stop offset="1" style="stop-color: #fda085" />
        </radialGradient>
        <polygon fill="url(#radialGradient2)" points="120,142 9,93 107,22"></polygon>
    </svg>
</div>

CSS

.svgBox .svg {width: 160px; height: 160px; background: #ffebee;}

TOTAL

<!DOCTYPE html>
<html lang="ko">
<head>
    <meta charset="UTF-8">
    <meta name="viewport" content="width=device-width, initial-scale=1.0">
    <meta http-equiv="X-UA-Compatible" content="ie=edge">
    <title>SVG</title>
    <style>
    .svgBox .svg {width: 160px; height: 160px; background: #ffebee;}
    </style>
</head>
<body>
    <div class="svgBox">
        <svg class="svg">
            <radialGradient id="radialGradient1" gradientUnits="userSpaceOnUse">
                <stop offset="0" style="stop-color: #f6d365" />
                <stop offset="1" style="stop-color: #fda085" />
            </radialGradient>
            <polygon fill="url(#radialGradient1)" points="130,128 65,148 15,102 30,36 95,16 145,62"></polygon>
        </svg>
        <svg class="svg">
            <radialGradient id="radialGradient2" gradientUnits="userSpaceOnUse">
                <stop offset="0" style="stop-color: #f6d365" />
                <stop offset="1" style="stop-color: #fda085" />
            </radialGradient>
            <polygon fill="url(#radialGradient2)" points="120,142 9,93 107,22"></polygon>
        </svg>
    </div>
</body>
</html>

호환성(Compatibility) 더보기 caniuse.com

						6	7	8	9	10	11
<radialGradient>	사용가능	사용가능	사용가능	사용가능	사용가능	사용안됨	사용안됨	사용안됨	사용가능	사용가능	사용가능	사용가능	사용가능	사용가능
