Rect Animation




Rect Animation



정의(Definition)

  • Rect Animation

1. Rect Animation

SVG를 이용한 Rect Animation입니다.

Sample1

HTML
<div class="svgBox">
    <svg class="svg">
        <rect class="aniRect1"></rect>
    </svg>
    <svg class="svg">
        <rect class="aniRect2"></rect>
    </svg>
    <svg class="svg">
        <rect class="aniRect3"></rect>
    </svg>
    <svg class="svg">
        <rect class="aniRect4"></rect>
    </svg>
</div>
CSS
.svgBox .svg {width: 160px; height: 160px; background: #ffebee;}
.aniRect1 {
    width: 120px; height: 120px; x: 20px; y: 20px;
    fill: none; stroke: #880e4f; stroke-width: 4;
    animation: rect1 4s infinite linear;
}
@keyframes rect1 {
    0% {stroke: #880e4f;}
    35% {stroke: #311b92;}
    70% {stroke: #004d40;}
    100% {stroke: #880e4f;}
}
.aniRect2 {
    width: 120px; height: 120px; x: 20px; y: 20px;
    fill: none; stroke: #880e4f; stroke-width: 4;
    animation: rect2 4s infinite linear;
    stroke-dasharray: 100;
    stroke-dashoffset: 100;
}
@keyframes rect2 {
    0% {stroke: #880e4f; stroke-dashoffset: 100;}
    35% {stroke: #311b92;}
    70% {stroke: #004d40;}
    100% {stroke: #880e4f; stroke-dashoffset: 0;}
}
.aniRect3 {
    width: 120px; height: 120px; x: 20px; y: 20px;
    fill: none; stroke: #880e4f; stroke-width: 4;
    animation: rect3 4s infinite linear;
    stroke-dasharray: 480;
    stroke-dashoffset: 480;
}
@keyframes rect3 {
    0% {stroke: #880e4f; stroke-dashoffset: 480;}
    35% {stroke: #311b92;}
    70% {stroke: #004d40;}
    100% {stroke: #880e4f; stroke-dashoffset: 0;}
}
.aniRect4 {
    width: 120px; height: 120px; x: 20px; y: 20px;
    fill: none; stroke: #880e4f; stroke-width: 4;
    animation: rect4 4s infinite linear;
    stroke-dasharray: 100;
    stroke-dashoffset: 100;
}
@keyframes rect4 {
    0% {stroke: #880e4f; stroke-dasharray: 100;}
    35% {stroke: #311b92;}
    70% {stroke: #004d40;}
    100% {stroke: #880e4f; stroke-dasharray: 0;}
}
TOTAL
<!DOCTYPE html>
<html lang="ko">
<head>
    <meta charset="UTF-8">
    <meta name="viewport" content="width=device-width, initial-scale=1.0">
    <meta http-equiv="X-UA-Compatible" content="ie=edge">
    <title>SVG</title>
    <style>
        .svgBox .svg {width: 160px; height: 160px; background: #ffebee;}
        .aniRect1 {
            width: 120px; height: 120px; x: 20px; y: 20px;
            fill: none; stroke: #880e4f; stroke-width: 4;
            animation: rect1 4s infinite linear;
        }
        @keyframes rect1 {
            0% {stroke: #880e4f;}
            35% {stroke: #311b92;}
            70% {stroke: #004d40;}
            100% {stroke: #880e4f;}
        }
        .aniRect2 {
            width: 120px; height: 120px; x: 20px; y: 20px;
            fill: none; stroke: #880e4f; stroke-width: 4;
            animation: rect2 4s infinite linear;
            stroke-dasharray: 100;
            stroke-dashoffset: 100;
        }
        @keyframes rect2 {
            0% {stroke: #880e4f; stroke-dashoffset: 100;}
            35% {stroke: #311b92;}
            70% {stroke: #004d40;}
            100% {stroke: #880e4f; stroke-dashoffset: 0;}
        }
        .aniRect3 {
            width: 120px; height: 120px; x: 20px; y: 20px;
            fill: none; stroke: #880e4f; stroke-width: 4;
            animation: rect3 4s infinite linear;
            stroke-dasharray: 480;
            stroke-dashoffset: 480;
        }
        @keyframes rect3 {
            0% {stroke: #880e4f; stroke-dashoffset: 480;}
            35% {stroke: #311b92;}
            70% {stroke: #004d40;}
            100% {stroke: #880e4f; stroke-dashoffset: 0;}
        }
        .aniRect4 {
            width: 120px; height: 120px; x: 20px; y: 20px;
            fill: none; stroke: #880e4f; stroke-width: 4;
            animation: rect4 4s infinite linear;
            stroke-dasharray: 100;
            stroke-dashoffset: 100;
        }
        @keyframes rect4 {
            0% {stroke: #880e4f; stroke-dasharray: 100;}
            35% {stroke: #311b92;}
            70% {stroke: #004d40;}
            100% {stroke: #880e4f; stroke-dasharray: 0;}
        }
    </style>
</head>
<body>
    <div class="svgBox">
        <svg class="svg">
            <rect class="aniRect1"></rect>
        </svg>
        <svg class="svg">
            <rect class="aniRect2"></rect>
        </svg>
        <svg class="svg">
            <rect class="aniRect3"></rect>
        </svg>
        <svg class="svg">
            <rect class="aniRect4"></rect>
        </svg>
    </div>
</body>
</html>

호환성(Compatibility) 더보기 caniuse.com

  크롬 아이콘 파이어폭스 아이콘 사파리 아이콘 오페라 아이콘 네이버 웨일 익스플로러6 아이콘6 익스플로러7 아이콘7 익스플로러8 아이콘8 익스플로러9 아이콘9 익스플로러10 아이콘10 익스플로러11 아이콘11 엣지 아이콘 안드로이드 아이콘 ios 아이콘
<view> 사용가능 사용가능 사용가능 사용가능 사용가능 사용안됨 사용안됨 사용안됨 사용가능 사용가능 사용가능 사용가능 사용가능 사용가능

참고(Reference)

  • MDN SVG
  • Scalable Vector Graphics (SVG)2
